China OEM 3 Inch Exhaust Pipe Connector Company

Product Description

Galvanized pipe fittings are essential components in piping systems. They serve to connect and join different sections of pipes, ensuring secure and leak-free connections. These fittings are made from galvanized steel, which is coated with a layer of zinc to protect against corrosion. They come in various shapes and types, including unions, elbows, tees, plugs, sockets, and bushings. Galvanized fittings are commonly used for outdoor and industrial applications to safeguard against rust and salt. While they work best with cold water lines, they are also suitable for hot water lines.

Galvanized pipe fittings offer several advantages:

  1. Corrosion Resistance: The zinc coating on galvanized fittings protects against rust and corrosion, making them ideal for outdoor and industrial applications.
  2. Durability: Galvanized steel is sturdy and long-lasting, ensuring reliable performance over time.
  3. Easy Installation: These fittings are threaded, allowing for straightforward assembly without specialized tools.
  4. Cost-Effective: Galvanized fittings are affordable and widely available.
  5. Compatibility: They work well with both cold and hot water lines.

Common sizes for galvanized pipe connectors:

  • 1 inch pipe connector
  • 1/2 pipe connector
  • 1/4 pipe connector
  • 2 inch exhaust pipe connector
  • 2.25 exhaust pipe connector
  • 2.5 exhaust pipe connector
  • 3 inch exhaust pipe connector
  • 3/4 inch pipe connector
  • 6 inch stove pipe connector

Fitting size and normal size (DN):

Fitting size Normal size (DN)
1/8 6
1/4 8
3/8 10
1/2 15
3/4 20
1 25
1 1/4 32
1 1/2 40
2 50
2 1/2 65
3 80
4 100
5 125
6 150
Product parameters:
Size: 1/4”-4”(DN8-DN100)
Standard: EN10242 / ANSI / ASME B16.3 / DIN2950 / IS0 49 / NBR6943 / IS1879 / BS EN10242
Threaded Standard: EN10226 / ASME B.1.20.1 / DIN2999 / ISO7-1 / ISO228 / IS554 / BS EN10226
Work Pressures: PN25 / 2.5Mpa / 363PSI /CLASS 150 / 25Bar
Certification: UL Listed /FM Approved /CE /ABNT /TSE /SNI /ISI

JIANZHI is a malleable Iron pipe fittings manufacturer supply professional OEM galvanized pipe fittings to the world. JIANZHI’s accessories are ideal for a variety of applications, including but not limited to:

  1. Pipeline system
  2. Heating and cooling systems
  3. Industrial processing systems
  4. Agricultural irrigation system

Galvanized Pipe Fittings

JANZHI-Malleable iron pipe fittings

Thread BSPT and NPT
EN10226 /ASMEB1.20.1/IS0228/IS07-1
International Certification
Extraordinary craftsmanship, perfection, and beauty
Free run-out structure
Protect pipe fittings from injury during connection
Free run-out:
Protect pipelines and fittings
black steel tube fittings
No Free run-out :
May cause damage to pipelines and fittings
disrupting their original performance
black steel tube fittings
*For more product performance testing videos,
please contact our staff
Thread quality higher than nationalstandards
Quick installation
70um Zinc layer thickness
Air pressure
0.6MPa

20%

national
standard
0.5MPa
Shaft Angle
±0.3°

40%

national
standard
+0.5°
Tensile strength
363MPa

10%

national
standard
330MPa
Elongation
12%

33%

national
standard
8%
Execution standards
Material:
EN1562 Or 1S0 5922
Design & Dimensions:
EN10242 0rIS0 49
Thread :
BSPT and NPT
logo

100% individuoltesting ofthe product

Thread angle
Shaft angle
Air tightness
Fully automatic detection
Width Detection
Mechanical properties
Device detection
Elongation
Zinc layer thickness
logo

Reduce carbon emissions and
use renewable energy
Focuson sustainable development

Start from 1982

Sam floot space

Tons of production per year

Tons nbentory

Sustainable Development
iso24001
iso9001
iso24001
10 Production process
Profiling – Smelt – Pouring – Anneal – Burnishing – Correct

|

Galvanization – Threading – Detail processing – Grinding

10 Production process
25Days
Designated brand in china
government group
partner
Designated brand in china
government group

Sold to over 30
countries and regions

AMAALA conrad hotel saudi arabia NEOM Security Forces

JANZHI Group holds 13.6% market share
Gas Pipeline System holds 60% market share

Official marketing material support
One to one customized service to meet the
customized needs of different customers
Officialafter-sales service
Professional personnel provide you with
after-sales service and technical support
One stop service to solve your logistics problems
24hours
Customer Service
Tailored project proposal for clients
logo
Request a quote
