Equal Grooved Cross

Category:

Product Description

Unveiling the Design and Functionality of the Equal Grooved Cross

The equal grooved cross is a specialized fitting designed to create a four-way intersection within piping configurations, ensuring equal flow distribution among interconnected branches. Featuring grooved ends that enable secure connections to grooved pipes, this cross eliminates the need for intricate welding or threading methods, simplifying installation processes while maintaining leak-free joints. Its symmetrical design and compatibility with grooved pipe systems make it an ideal choice for applications requiring balanced fluid distribution and efficient fluid transportation.

Grooved Cross is used for grooved pipeline connection, mainly used in the grooved pipe end of the main pipeline where branch pipes are needed. The pipe diameter of the main pipe and the branch pipe are the same.

Diverse Applications Across Industries

The versatility of the equal grooved cross makes it a key component in a wide range of industries, including HVAC systems, water treatment plants, chemical processing facilities, and more. In HVAC systems, these crosses play a crucial role in achieving uniform airflow distribution and promoting system efficiency by ensuring consistent flow rates in all directions. Within water treatment plants, they facilitate seamless fluid transfer between different treatment stages, optimizing process efficiency and performance.

Advantages

  • Uniform Flow Distribution: The equal grooved cross ensures equal distribution of fluids among interconnected branches, promoting balanced flow rates and pressure across the system.
  • Simplified Installation: With grooved ends that enable quick and secure connections without the need for specialized tools, these crosses streamline assembly processes, reducing installation time and labor costs.
  • Enhanced System Efficiency: By maintaining equilibrium in flow distribution and minimizing pressure differentials, the equal grooved cross enhances system performance and reliability, contributing to overall operational efficiency.

Equal Grooved Cross Parameter Table

Equal Grooved Cross
