Union Pipe Fitting Male and Female Brass Taper Seat Fig. 343

Maximum Pressure:

25 BAR (363PSI) (2.5MPA) CLASS 150

Maximum Temperature:

200°C (392°F)

Tensile Strength:

350MPA

Suitable Applications:

Water, Oil, Gas, Petro-Chemical

Size: 1/2”-2”
Standard: EN10242 / ANSI / ASME B16.3 / DIN2950 / IS0 49 / NBR6943 / IS1879 / BS EN10242
Threaded Standard: EN10226 / ASME B.1.20.1 / DIN2999 / ISO7-1 / ISO228 / IS554 / BS EN10226
Work Pressures: PN25 / 2.5Mpa / 363PSI /CLASS 150 / 31Bar
UL Listed /FM Approved /CE /ABNT /TSE /SNI /ISI

Would like to see how our high accuracy union is made?

You can follow our youtube channel or facebook. You will find the answer.

Product Description

Brass Taper seat union with internal and external thread, has good sealing tightness , can contect the pipes with the end of external thead and other end of internal thread.

Maximum Pressure: 25 BAR (363PSI) (2.5MPA) CLASS 150
Maximum Temperature: 200°C (392°F)
Tensile Strength: 350MPA
Hardness: HB150 (Brinell)
Elongation Rate: 12%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Malleable Iron

When you buy, please make sure that this key has a male interface and a female interface. The union of the cone seat guarantees a better seal and ensures that your piping system does not leak. The cone seat of this union is made of copper, which will further improve the sealing.

Brass-Unions-Taper-Seat

JANZHI-Malleable iron pipe fittings

Thread BSPT and NPT
EN10226 /ASMEB1.20.1/IS0228/IS07-1
International Certification
Extraordinary craftsmanship, perfection, and beauty
Free run-out structure
Protect pipe fittings from injury during connection
Free run-out:
Protect pipelines and fittings
black steel tube fittings
No Free run-out :
May cause damage to pipelines and fittings
disrupting their original performance
black steel tube fittings
*For more product performance testing videos,
please contact our staff
Thread quality higher than nationalstandards
Quick installation
70um Zinc layer thickness
Air pressure
0.6MPa

20%

national
standard
0.5MPa
Shaft Angle
±0.3°

40%

national
standard
+0.5°
Tensile strength
363MPa

10%

national
standard
330MPa
Elongation
12%

33%

national
standard
8%
Execution standards
Material:
EN1562 Or 1S0 5922
Design & Dimensions:
EN10242 0rIS0 49
Thread :
BSPT and NPT
logo

100% individuoltesting ofthe product

Thread angle
Shaft angle
Air tightness
Fully automatic detection
Width Detection
Mechanical properties
Device detection
Elongation
Zinc layer thickness
logo

Reduce carbon emissions and
use renewable energy
Focuson sustainable development

Start from 1982

Sam floot space

Tons of production per year

Tons nbentory

Sustainable Development
iso24001
iso9001
iso24001
10 Production process
Profiling – Smelt – Pouring – Anneal – Burnishing – Correct

|

Galvanization – Threading – Detail processing – Grinding

10 Production process
